B-63484EN/05 10.EXTENDED SYMBOL/COMMENT FUNCTION

- 359 -

10.5 CONVERTING TO SOURCE PROGRAMS

1 When the mnemonic file of non-extended functions is converted

into the source of extended functions, the unusable character in

the symbol is replaced as follows.

• Replacement of the symbol character. (Identification

code: %@2-C, %@2-C2)

Tabel 10.5 (a)

Unusable

character

Replacement

characters

Remarks

% (Percent) _PR_

When the 1st character of the symbol is "%", it is replaced with the

replacement characters.

$ (Dollar) _DR_

When the 1st character of the symbol is "$", it is replaced with the

replacement characters.

: (Colon) _CR_ ":" in the symbol is replaced with the replacement characters.

; (Semicolon) _SC_ ";" in the symbol is replaced with the replacement characters.

. (Period) _PE_ "." in the symbol is replaced with the replacement characters.

• Replacement of the symbol character of the ladder data

Tabel 10.5 (b)

Unusable

character

Replacement

characters

Remarks

% (Percent)

"%" cannot be used for the 1st character of the symbol.

Reason)

• The same as the identification code.

• The same as the address of extended function.

Replace the unusable characters in the mnemonic file.

$ (Dollar) _DR_

When the 1st character of a symbol is "$", it is replaced to the replacement

characters.

: (Colon)

":" cannot be used for the symbol.

Reason)

The character before ":" is deleted.

Replace the unusable characters in the mnemonic file.

; (Semicolon)

";" cannot be used for the symbol.

Reason)

The character after ";" is deleted.

Replace the unusable characters in the mnemonic file.

. (Period) _PE_ "." in the symbol is replaced to the replacement characters.

2 In conversion of the mnemonic, if you select the

"Label/Subprogram", the ladder data is outputted in the symbol.

If you select the "P-G Compatible" and the "Full Options", the

ladder data is outputted in the address. When you convert the

ladder of the non-extended function into the extended function,

select the "Full Options" and convert into the mnemonic.

3 In case of mnemonic file of extended format, whose ID is

“%2-D”, converting such characters in a symbol causes an error.
