6.MNEMONIC EDITING B-63484EN/05

- 232 -

PMC model Setting data (half-size string)

32i-A PMC

32i-A PMC(2nd)

32i-A PMC(3rd)

32i-A PMC(DCS)

32i-A PMC(EXT)

32i-A PMC(2nd,EXT)

32i-A PMC(3rd,EXT)

32i-A PMC(DCS,EXT)

PMC-SA1 PMC-RA1

PMC-SA3 PMC-RA3

PMC-SA5 PMC-RA5

PMC-SB3 PMC-RB3

PMC-SB4 PMC-RB4

PMC-SB4 (STEP SEQ) PMC-RB4 (STEP SEQ)

PMC-SB5 PMC-RB5

PMC-SB6 PMC-RB6

PMC-SB6 (STEP SEQ) PMC-RB6 (STEP SEQ)

PMC-SB6 (IO-2) PMC-RB6 (IO-2)

PMC-SB6 (STEP,I/O-2) PMC-RB6 (STEP,I/O-2)

PMC-SB7 PMC-SB7

PMC-SB7 (STEP SEQ) PMC-SB7 (STEP SEQ)

PMC-SC3 PMC-RC3

PMC-SC4 PMC-RC4

PMC-SC4 (STEP SEQ) PMC-RC4 (STEP SEQ)

PMC-NB PMC-NB

PMC-NB2 PMC-NB2

PMC-NB6 PMC-NB6

PMC-PA3 PMC-PA3

PMC-QC PMC-QC

Head address of language program link control statement data

0, or 800000 to 8FFFFF (hex)

Time ratio to execute language program

1 to 99 (%)

Ladder execution time

100 (always 100%)

I/O link assignment selection function (channel 1)

Used: USE

Not used: UNUSE

Number of basic I/O link groups (channel 1)

0 to 16

I/O link assignment selection function (channel 2)

Used: USE

Not used: UNUSE

Number of basic I/O link groups (channel 2)

0 to 16
