Open CNC (Ladder Editing Package, Windows) Operators manual Page 246

Operators manual
5.COMPILATION AND DECOMPILATION B-63484EN/05
- 218 -
Operation
1 Select [Tool]-[Compile...]. Then, the [Compile] dialog appears.
2 Click the <Exec> button.
3 If compile processing is completed, the error and warning are
displayed.
NOTE
1 The result of automatic assignment is output to the
map log. Push the <Map Log> button to display the
net number, the functional instruction and the
automatic assigned parameter number.
2 You can check duplication of the parameter
number of the functional instruction TMR, TMRB,
TMRBF, CTR, CTRB, DIFU, and DIFD. Please
check the Multiple used check of the Function
parameter number of the [option] tab of the
[compile] screen.
3 You cannot check the automatically generated
number on the offline editing screen because
automatic numbering function generates the
parameter number in the ladder object code
directly. But you will be able to check the
automatically generated number on the online
editing screen.
