12.ERROR MESSAGES B-63484EN/05

- 406 -

Error code Message Cause/action

K:W-4111

Message data include KANA OR KANJI

characters at ****.

Message data **** includes full-size/half-size katakana

characters.

K:W-4112 Not enough control condition(s).

Not all necessary control conditions are set for a function

instruction.

K:W-4113 Not found data at **** address. At address ****, no message is defined.

Not found parameter numbered ****.

K:W-4114

Not found title numbered $.

K:W-4116 Not found **** PMC-OS file..

K:W-4117 Not used net comment pointer exist. $

K:W-4118 Output unused register(s).

K:W-4119 Overwrote existing data.

K:W-4120 Invalid qualifier.

An invalid character follows the end ID code (%) of each data

item (system parameter, message data, title data, ladder,

symbol/comment, and I/O module data).

K:W-4121 Registers overflow.

K:W-4122

Some garbage data are found at end of

ladder data.

Upon conversion to FORMAT-B, data that does not belong to the

first to third levels or any sub-programs was found.

This message is output when data is found after the last SPE

instruction.

K:W-4123 Specify same group base and slot.

In the I/O module data, the same number is specified for group,

base, and slot data.

K:W-4124

Specify same number( Group ) at I/O

UNIT-B as I/O UNIT-A.

K:W-4125

Specify the value( Base ) except 0 at

I/O UNIT-B.

K:W-4126

The following data of **** were deleted

because of exceeding the limit.

K:W-4127 Too many control conditions. Too many control conditions are set for a function instruction.

K:W-4128 Unexpected coil(s).

Coils were specified for a function instruction that requires no

coils.

K:W-4129 Unexpected control condition(s).

A basic instruction was specified for a function instruction that

requires no control condition.

Redefinition of address data.

K:W-4130

Illegal net comment pointer. ****

A symbol definition is made at more than one location for the

same address. If the start ID code of symbol data is %@2, no

duplicate definition is allowed. The definition or definitions made

later are ignored.

K:W-4131 Redefinition of symbol data.

The same symbol data was specified for different addresses.

The symbol data defined later is replaced with blank characters.

K:W-4132 Too long strings for symbol data.

FORMAT-A/B allows up to 6 characters.

FORMAT-C allows up to 16 characters.

Symbol data is replaced with blank characters.

K:W-4133 Too long strings for comment data.

A maximum of 30 characters can be specified.

Comment data is replaced with blank characters.

K:W-4134 symbol data already exist.

For one address, a different symbol is specified at more than one

location. (With FORMAT-C, the same symbol may be specified

at more than one location.)

The symbol data specified later is replaced with blank characters.

K:W-4135 relay comment data already exist.

For a relay comment at one address, a different character string

is specified at more than one location. (With FORMAT-C, the

same character string may be specified at more than one

location.)

The relay comment data specified later is replaced with blank

characters.
