E.THE DATA FORMAT OF THE EXTERNAL SYMBOL FILE APPENDIX B-63484EN/05

- 442 -

To read the external symbol file of 30i/31i/32i-A extended function in

30i/31i/32i-A

- Operation

1 Display the export screen in 30i/31i/32i-A extended function.

Check Performing automatic address assignment. Output the

external symbol file.

2 Display the import screen in 30i/31i/32i-A, and input the external

symbol file.

3 When reading the external symbol file for 30i/31i/32i-A, there

are the following limitations.

Table E.3 (a) Limitations

Items Contents

The symbol

character is over

17 characters.

The symbol is not read.

Reads the address and the comment, when there is the

comment.

The comment

character is over

31 characters.

Reads to until 30 characters.

The 1st comment and the 2nd comment are read as the

comment of 30 characters.

The 3rd comment and the 4th comment are not read.

Local symbol The local symbol is not read.

Only the global symbol is read.

Automatically

assigned

address

Cannot read the symbol of only the address character.

When you output the external symbol file, assign the

address using the automatic address assignment

function.
