B-63484EN/05 12.ERROR MESSAGES

- 407 -

Error code Message Cause/action

K:W-4136 coil comment data already exist.

For a coil comment at one address, a different character string is

specified at more than one location. (With FORMAT-C, the same

character string may be specified at more than one location.)

The coil comment data specified later is replaced with blank

characters.

K:W-4137 comment title data already exist.

For a comment title at one address, a different character string is

specified at more than one location. (With FORMAT-C, the same

character string may be specified at more than one location.)

The comment title data specified later is deleted.

K:W-4138

Too long strings for relay comment

data.

The character string of a relay comment is longer than 16

characters. With FORMAT-C only, relay comment data is

replaced with blank characters.

K:W-4139 Too long strings for coil comment data.

The character string of a coil comment is longer than 30

characters. With FORMAT-C only, coil comment data is replaced

with blank characters.

K:W-4140 Too long strings for comment title data.

The character string of a comment title is longer than 30

characters. With FORMAT-C only, comment title data is replaced

with blank characters.

K:W-4143

The symbol replaced by the specified

character was not output because it

was duplication definition.

K: W-7000 The space code of the symbol data was

replaced with the specification

character.

The white-space character of a symbol was replaced with the

specified character.

K:W-7001

This symbol cannot be defined as the

local symbol.(Symbol, Address)

K:W-7002

The space code exists in the symbol

data.

K:W-7003

The symbol of the same name as the

already inputted local symbol cannot be

inputted.(Prog., symbol)

K:W-7004 Too long strings for third comment data.

K:W-7005

Too long strings for fourth comment

data.

K:W-7006 Third comment data already exist.

K:W-7007 Fourth comment data already exist..

K:W-7008

It skipped because there was no

symbol.

K:W-7009

The symbol that used the limitation

character was skipped.(Prog., Symbol)

K:W-7010

The symbol that used the limitation

character was replaced.(Prog., Symbol)

K:W-7011 Address and Type does not exist.

K:W-7012 Type is illegal.(Type)

K:W-7013

Address and Type are

contradictory.(Address, Type)

K:W-7014

Address or Type is illegal.(Address,

Type)"

K:W-7015 Type was changed to LABEL.

K:W-7016 Type cannot be changed.

K:W-7017 Type was changed to PROG.

K: W-7018 Address is illegal. Confirm the address and change into the right address.
