Open CNC (Ladder Editing Package, Windows) Operators manual Page 31

Operators manual

Page of 571

/ 571

B-63484EN/05 1.SETUP

- 3 -

• CNC functions

Options for FANUC open-ended CNCs

<For Series 150 / Series 150i>

⋅ Expansion driver library function (A02B-0207-J801)

⋅ Ladder editing package function (A02B-0207-J821)

<For Series 16 / Series 18 / Series 16i / Series 18i / Series 21i>

⋅ Expansion driver library function (A02B-0207-J800)

⋅ Ladder editing package function (A02B-0207-J820)

<For Series 160 / Series 180 / Series 160i / Series 180i / Series

210i>

⋅ Expansion driver library function (A02B-0207-J800)

⋅ Ladder editing package function (A02B-0207-J820)

<For Series 0i-B / Series 0i-C>

⋅ Expansion driver library function (A02B-0207-J800)

⋅ Ladder editing package function (A02B-0207-J820)

<For Power Mate i-MODEL D/ Power Mate i-MODEL H>

⋅ Expansion driver library function (A02B-0259-J847)

⋅ Ladder editing package function (A02B-0259-J848)

<For Series 30i / Series 300i / Series 300is-MODEL A>

⋅ Expansion driver library function (A02B-0207-J900)

⋅ Ladder editing package function (A02B-0207-J820)

<For Series 31i / Series 310i / Series 310is-MODEL A>

⋅ Expansion driver library function (A02B-0207-J900)

⋅ Ladder editing package function (A02B-0207-J820)

<For Series 32i / Series 320i / Series 320is-MODEL A>

⋅ Expansion driver library function (A02B-0207-J900)

⋅ Ladder editing package function (A02B-0207-J820)

NOTE

It is recommended that the Ladder Editing Package

(Windows) be used on Windows 98 SE, Windows

NT 4.0, Windows 2000, Windows Me, or Windows

XP.
