Open CNC (Ladder Editing Package, Windows) Operators manual Page 261

Operators manual
B-63484EN/05 6.MNEMONIC EDITING
- 233 -
The parameters for each model are described below.
(1) For PMC-PA3/SA3/SA5/SB4/SB5/SB6
%@0
2 BINARY
3 NO
4 PMC-RB5
%
2. Counter data type
3. Presence or absence of operator panel
4. PMC type
(BINARY or BCD)
(Presence: YES, Absence: NO)
(PMC-PA3/PMC-RA3/PMC-RA5/PMC
-RB4/PMC-RB5/PMC-RB6)
(2) For PMC-SB3/NB6
%@0
2 BINARY
3 NO
4 PMC-NB6
7 100
%
2. Counter data type
3. Presence or absence of operator panel
4. PMC type
7. Ladder execution time
(BINARY or BCD)
(Presence: YES, Absence: NO)
(PMC-RB3/PMC-NB6)
(fixed at 100%)
(3) For PMC-SC3/SC4
%@0
2 BINARY
3 NO
4 PMC-RC3
5 000000
6 50
7 100
%
2. Counter data type
3. Presence or absence of operator panel
4. PMC type
5. Head address of language program link control
statement data
6. Time ratio to execute language program
7. Ladder execution time
(BINARY or BCD)
(Presence: YES, Absence: NO)
(PMC-RC3/PMC-RC4)
(0 or 800000 to 8FFFFF(hex))
(1 to 99%)
(fixed at 100%)
(4) For PMC-NB/NB2
%@0
2 BINARY
3 NO
4 PMC-NB
5 000000
6 50
7 100
%
2. Counter data type
3. Presence or absence of operator panel
4. PMC type
5. Head address of language program link control
statement data
6. Time ratio to execute language program
7. Ladder execution time
(BINARY or BCD)
(Presence: YES, Absence: NO)
(PMC-NB/PMC-NB2)
(0 or 200000 to 2FFFFF(hex))
(1 to 99%)
(fixed at 100%)
(5) For PMC-SB7
%@0
2 BINARY
3 NO
4 PMC-SB7
7 150
11 UNUSE
12 0
13 UNUSE
14 0
%
2. Counter data type
3. Presence or absence of operator panel
4. PMC type
7. Ladder execution time
11. I/O link assignment selection function
12. Number of basic I/O link groups
13. I/O link assignment selection function
14. Number of basic I/O link groups
(BINARY or BCD)
(Presence: YES, Absence: NO)
(PMC-SB7)
(Used: USE, Not used: UNUSE) (channel 1)
(0 to 16) (channel 1)
(Used: USE, Not used: UNUSE) (channel 2)
(0 to 16) (channel 2)
