B-63484EN/05 6.MNEMONIC EDITING

- 221 -

4 Select [Selection Item]. The following items can be selected:

Table 6.1 (b)

P-G Compatible

• Converts data to data in the format output by

P-G.

• Converts Japanese messages to code-formatted

data.

Full Options

• Converts comments in which kanji characters

are included in the comment data.

• Converts data in which the symbol and comment

for an address as well as the function name of a

function are used as comments.

• Converts data that has an instruction part,

operand part, and comment part.

• Converts Japanese messages to

Japanese-formatted data.

Label/Subprogram

• Converts data with the jump addresses (labels)

of functions (JMPB, JMPC, CALL, SP

commands) used in a subprogram highlighted.

However, the step number of mnemonic data

after conversion is different from the other

settings. (The function part used in a

subprogram is different.)

• Converts Japanese messages to

Japanese-formatted data.

5 To convert a source program to a mnemonic file, click the <OK>

button. Once the conversion is completed, the conversion results

appear.

(To see the last converted results, click the <Log File> button.)

6.1.1 Converts to the External Symbol File

This function outputs the symbol/comment of external symbol file

format. External symbol files are composed of identification code and

the comma separated text file. You can edit the symbol/comment data

by the external application such as Microsoft Excel, Text editor.

The same data as the one explained in "3.11.2 Export of the external

symbol file" is outputted.
