Open CNC (Ladder Editing Package, Windows) Operators manual Page 430

Operators manual

Page of 571

/ 571

12.ERROR MESSAGES B-63484EN/05

- 402 -

Error code Message Cause/action

K:F-2103 Insufficient parameter(s). System parameter /function instruction data is insufficient.

K:F-2104 Too many parameters. Too many parameters are specified in a function instruction.

K:F-2105 Illegal Option-specified file.

K:F-2106 Illegal Idcode.

K:F-2107 Expected terminator.

K:F-2108

PMC series is different from

Source-program.

K:F-2109 Expected Idcode.

K:F-2110 Illegal parameter(s).

K:F-2111

Create temporary file(s) in current

directory.

K:F-2112

Not specified environmental variable

'TMP'.

K:F-2113 Illegal name of Set-up file.

K:F-2114 Not found Set-up file.

K:F-2115 Expected '/PC' option.

K:F-2116 **** executable file not found.

K:F-2117 Input data illegal.

K:F-5001 Prog. is illegal.(Prog.)

K:F-5002 Prog. is out of range.(Prog.)

**** file cannot execute.

K:E-3100

The file cannot be executed.

The data of **** is broken.

K:E-3101

* Symbol & Comment data broken.

K:E-3102 Cannot be handle data type '%@2-C'.

When the format of %%%FLSET.CNF is FORMAT-A/B, the

mnemonic of the extended symbol %@2-C was converted.

Cannot convert files of the PMC series

set up the system.

K:E-3103

The model set with the system cannot

be converted.

K:E-3104 Cannot overwrite existing data.

K:E-3105

Cannot specify bit address of

parameter.

A bit address was specified in a byte address parameter of a

function instruction.

K:E-3106

Cannot specify byte address on basic

instruction.

A byte address was specified in a basic instruction.

K:E-3107

Cannot specify output module at input

address.

An output module is specified at the input address of I/O module

data.

K:E-3108

Cannot specify input module at output

address.

An input module is specified at the output address of I/O module

data.

K:E-3109

Cannot specify the address prohibited

using as parameter.

A parameter prohibition address was specified in the address

parameter of a function instruction.

K:E-3110 Cannot specify the bit address.

K:E-3111 Cannot specify the byte address.

K:E-3112 Cannot specify the input address.

An output prohibition address was specified in the output address

parameter of a function instruction.

K:E-3113

Cannot specify the input address with

coil.

An output prohibition address was specified for a coil.

K:E-3114 Cannot specify the odd address.

An odd-numbered prohibition address was specified as an

odd-numbered address.

K:E-3117 Expected a multiple of 2.

A system parameter includes a numeric value that is not a

multiple of 2.
