B-63484EN/05 10.EXTENDED SYMBOL/COMMENT FUNCTION

- 375 -

CAUTION

1 Please input a symbol and a comment from the 1st

character. Any blank should not precede.

2 When using a single quotation mark " ' " into the

character string of a relay comment and a coil

comment, dollar + single quotation mark " $ "+ " ' "

describes.

3 When you use yen symbol " \ " (backslash) by a

comment into a comment text, please describe it as

two " \\. "

%@2-D

INITIALIZE L0100:LABEL

$1 'INITIALIZE OF SEQUENCE'

OPEN-FRONT P0008:PROG

$2 'OPEN FRONT COVER'

UNIT-2-ACT R0200.1:BOOL

$1 'KEEP UNIT-4 $$POWER$' ON'

$2 '$'POWER$$'

UNIT-3-POWER R0200.0:BOOL

$1 'KEEP UNIT-3 POWER ON'

$2 'KEEP POWER ON'

R0300.0:BOOL

$1 'KEEP UNIT-4 POWER ON'

$2 'KEEP POWER ON'

$LEVEL1

*ESP G0008.4:BOOL

$1 'Emergency STOP'

Work1 R0100.0:BOOL

$1 'Work signal\nTest'

Fig. 10.18.2 (b)
