FANUC OPEN CNC LADDER EDITING

PACKAGE (Windows) SUPPLEMENTARY

OPERATOR’S MANUAL

01 05/01/14 First issue B-63484EN/05-1

EDIT

DATE

DESIG.

DESCRIPTION

3/60

TITLE

DRAW.NO.

SHEET

CUST.

1. Outline

The FANUC PMC programming tool “LADDER EDITING PACKAGE (Windows)“ has been revised as

listed below.

Contents of change

Copy/paste of ladder diagram between different PMC types

Ladder program difference display function

Dividing mnemonic file by conversion

Transferring multi-language PMC message data to PMC and writing into F-ROM

Addition of control data for extra relay (E)

This manual is a supplementary manual for the above “Contents of change”.

Other explanations (existing functions, operation, etc.) are described in the following manual.

Name of Manual Spec.No.

FANUC OPEN CNC LADDER EDITING PACKAGE (Windows) OPERATOR'S MANUAL B-63484EN

2. Applied Software

The contents of change described herein apply to the following software.

 FANUC OPEN CNC LADDER EDITING PACKAGE (Windows)

Name Specification Version

FANUC OPEN CNC LADDER EDITING PACKAGE (Windows) A08B-9210-J511 4.80 or later

CNC System software

Software Drawing number Series Edition

Series 30i/ 300i/ 300is-MODEL A

CNC System Software

A02B-0303-H501#G002

A02B-0303-H501#G012

A02B-0303-H501#G022

G002

G012

G022

6.1 or later

Series 31i/ 310i/ 310is-MODEL A

CNC System Software

A02B-0307-H501#G101

A02B-0307-H501#G111

G101

G111

6.1 or later

Series 31i/ 310i/ 310is-MODEL A5

CNC System Software

A02B-0306-H501#G121

A02B-0306-H501#G131

G121

G131

6.1 or later

Series 32i/ 320i/ 320i-MODEL A

CNC System Software

A02B-0308-H501#G201 G201

6.1 or later

PMC Managing software

Software Drawing number Series Edition

Series 30i/ 31i/ 32i PMC System Software

A02B-0303-H580#40A0 40A0 06 or later
