B-63484EN/05 3.CREATING AND EDITING SEQUENCE PROGRAMS

- 25 -

3.1.3 Work Folders and Online Program Files

• Work folder

A program work folder is created automatically on a path set up

in the TMP environment variable. The work folder is called

WFLAD* where * represents any number.

• User file folder

A user file folder, called MyFladder, is created automatically in

the work folder mentioned above. A user file can be saved if

required, along with other data files, to a LAD file, when LAD

programs are saved.

When PMC parameters are transferred with the input/output

function, PMC_PRM.PRM in the user file folder is initially set

for a parameter file transfer destination and transfer source file

name.

• Online program file

If communication is started with no program open, a program is

loaded from the PMC, and the following LAD files are created

automatically in the LAD folder.

⋅ If connected with the main PMC:

PMC0000.LAD to PMC0009.LAD

⋅ If connected with the loader PMC:

PMC1000.LAD to PMC1009.LAD

⋅ If connected with 1’st PMC:

PMC0000.LAD to PMC0009.LAD

⋅ If connected with 2’nd PMC:

PMC0100.LAD to PMC0109.LAD

⋅ If connected with 3’rd PMC:

PMC0200.LAD to PMC0209.LAD

⋅ If connected with PMC for Dual check safety:

PMC0800.LAD to PMC0809.LAD

These files are referred to as online program files.

When there is an online program file, and if communication is

started with no program opened, an online program file that

matches that on the PMC is opened automatically. Therefore, the

program can be debugged online without loading it from the

PMC so often.

NOTE

Up to ten online program files can be held. When

you finish debugging program, save the program

file under a different file name.
