1.SETUP B-63484EN/05

- 2 -

1.1 OPERATING ENVIRONMENT

The operating environment required for this software is as follows:

• Computer

PC/AT-compatible computer running Windows 98 SE, Me,

NT4.0, 2000 or XP.

• For Windows 98 SE

⋅ Pentium 133MHz or better CPU

⋅ 16MB or more memory (32MB or more recommended)

• For Windows NT 4.0

⋅ Pentium 166MHz or better CPU

⋅ 24MB or more memory (32MB or more recommended)

• For Windows Me or 2000

⋅ Pentium 166MHz or better CPU

⋅ 32MB or more memory (64MB or more recommended)

• For Windows XP

⋅ Pentium II 333MHz or better CPU

⋅ 64MB or more memory

• Hard disk

⋅ 30MB of free space required (at installation)

⋅ 120MB of free space required (at execution)

NOTE

Time required for ladder diagram editing and

processing of symbols and net comments is

affected by the free spaces of memory and the

hard disk. When handling a source program

including many ladders, symbols, comments, or net

comments or editing ladder diagrams on multiple

screens, allocate much more free spaces as far as

possible.

• Device driver

FANUC Open CNC Drivers and Libraries (A02B-0207-K737)

FANUC Open CNC Drivers and Libraries

(A02B-0207-K730(HSSB))
