Open CNC (Ladder Editing Package, Windows) Operators manual Page 538

Operators manual
FANUC OPEN CNC LADDER EDITING
PACKAGE (Windows) SUPPLEMENTARY
OPERATOR’S MANUAL
01 05/01/14 First issue B-63484EN/05-1
EDIT
DATE
DESIG.
DESCRIPTION
39/60
TITLE
DRAW.NO.
SHEET
CUST.
(4) “Local symbol” or “Global & Local Symbol” can be selected in extended function.
When [Local Symbol] is selected, all local symbols defined in the subprogram are output.
When [Global & Local Symbol] is selected, all local symbols defined in the sub program and only the global
symbols used in the subprogram are output.
File is divided and is output as follows.
Output Data Output file name
LEVEL1 PRG00LEVEL1.TXT
LEVEL2 PRG00LEVEL2.TXT
Ladder & Symbol&Comment
SubProgram Pn PRG00Pn.TXT
The LEVEL1 program and the Symbols used in the LEVEL1 program are output to
PRG00LEVEL1.TXT.
%@2-D
MF F0007.0:BOOL
$1 '1ST M-FUNCTION. STROBE SIGNAL'
MF-DEC P0002:PROG
$1 'M FUNCTIONS DECODING'
$LEVEL1
ON_PAS R0010.0:BOOL
$1 'MTR ALM'
%
%@3-D
RD *ESP ;<G8.4 > "Emergency STOP"
;[KEEP POWER ON]
WRT Work ;<R100.0 > "Work signal"
END1
%
