Open CNC (Ladder Editing Package, Windows) Operators manual Page 307

Operators manual
B-63484EN/05 9.DIAGNOSIS
- 279 -
9.1.4 Signal Trigger Stop Function
9.1.4.1 Procedure
1 If the offline mode is set, choose [Online/Offline] from the
[Ladder] menu to set the online mode.
The offline mode is set when the <Online/Offline Switch> button
is up. The online mode is set when the button is down.
<<Online/Offline Switch> button>
2 Choose [Ladder Mode - Signal Trigger] from the [Ladder] menu.
The <Signal Trigger> button is held down, and the [Signal
Trigger] screen appears. At the bottom of the screen, Trigger
Mode, Check Point, Address, Count, and Time are displayed.
(See Subsection 9.1.4.4, "[Trigger Parameter] screen.")
Fig. 9.1.4.1
