12.ERROR MESSAGES B-63484EN/05

- 388 -

12.2 ERROR MESSAGES

12.2.1 File

Error code Message Cause/action

A:F-2000 Insufficient memory

A:F-2001 Insufficient disk space

A:F-2004

This data can not be handled at this

version of FAPT LADDER

The source program includes an invalid file or does not include a

necessary file.

A:F-2005 Source program has wrong file

Check the file configuration of the source program.

A:F-2006 Not found **** file

A:F-2007 Not found **** Source program

A:F-2008 Cannot open **** file

A:F-2009 Cannot close **** file

A:F-2010 **** Source program broken

A:E-3120 Enter program name

No source program is entered. Enter the name of the desired

source program.

A:E-3121 The source program does not exist

A source program for an unsupported model was entered. Check

the models supported by this system.

A:E-3122 PMC model file is not found

Some system files (****.TBL) are not found. Reinstall.

A:E-3124 Cannot create new program ****

An entered source program cannot be created. A source

program cannot be created if a folder with the same name

already exists. Enter another program name.

A:E-3125 Illegal path of source program name

A specified path is not found. Check the entered source program

name.

A:E-3126 Source program type is different

In source program copy operation, a program of FORMAT-A/B

was specified. FORMAT-A/B cannot be used with Ladder Editing

Package (Windows). Convert the program by using the data

conversion function of the [Tool] menu.

A:E-3127 Mismatched password

A:E-3128 **** file read error The **** file cannot be read.

A:E-3130 **** file read error. Hit any key The **** file cannot be read.

A:E-3131 **** file open error The **** file cannot be opened.

A:E-3132 **** file close error The **** file cannot be closed.

A:E-3133 insufficient disk error

A file cannot be output due to there being insufficient disk

capacity. Terminate the system, and then the free up space on

the disk.

A:E-3134

Invalid option initialized.(**** file was

updated.

The option file was initialized because its data was destroyed.

A:E-3135

Program conversion error.(ROM ->

Memory card) Hit any key

A:E-3136

Program conversion error.(Memory card

-> ROM) Hit any key

A:E-3137 Cannot create file **** The **** file could not be created.

A:E-3138 Illegal source program name

A:E-3139 Illegal **** source program name

A:E-3140 Not found file

A:E-3141 Not found **** PMC-OS file

A:E-3143 Cannot open file The **** file cannot be opened.
