Open CNC (Ladder Editing Package, Windows) Operators manual Page 265

Operators manual
B-63484EN/05 6.MNEMONIC EDITING
- 237 -
(20) For 32i-A PMC (3rd-path PMC)
%@0
2 BINARY
3 NO
4 32i-A PMC(3rd)
31 1
32 -1
33 0
%
2: Counter data type
3: Presence or absence of operator panel
4: PMC type
31: Number of display language (comment)
32: CNC display language number 1
33: Comment set number 1
(BINARY or BCD)
(Presence: YES, Absence: NO)
(32i-A PMC(3rd))
(1-16)
(-1, 0-127)
(0-16)
(21) For 32i-A PMC (Dual check safety)
%@0
2 BINARY
3 NO
4 32i-A PMC(DCS)
31 1
32 -1
33 0
%
2: Counter data type
3: Presence or absence of operator panel
4: PMC type
31: Number of display language (comment)
32: CNC display language number 1
33: Comment set number 1
(BINARY or BCD)
(Presence: YES, Absence: NO)
(32i-A PMC(DCS))
(1-16)
(-1, 0-127)
(0-16)
(22) For 32i-A PMC (1st-path PMC, Extended function)
%@0
2 BINARY
3 NO
4 32i-A PMC(EXT)
31 1
32 -1
33 0
%
2: Counter data type
3: Presence or absence of operator panel
4: PMC type
31: Number of display language (comment)
32: CNC display language number 1
33: Comment set number 1
(BINARY or BCD)
(Presence: YES, Absence: NO)
(32i-A PMC(EXT))
(1-16)
(-1, 0-127)
(0-16)
(23) For 32i-A PMC (2nd-path PMC, Extended function)
%@0
2 BINARY
3 NO
4 32i-A PMC(2nd,EXT)
31 1
32 -1
33 0
%
2: Counter data type
3: Presence or absence of operator panel
4: PMC type
31: Number of display language (comment)
32: CNC display language number 1
33: Comment set number 1
(BINARY or BCD)
(Presence: YES, Absence: NO)
(32i-A PMC(2nd, EXT))
(1-16)
(-1, 0-127)
(0-16)
(24) For 32i-A PMC (3rd-path PMC, Extended function)
%@0
2 BINARY
3 NO
4 32i-A PMC(3rd)
31 1
32 -1
33 0
%
2: Counter data type
3: Presence or absence of operator panel
4: PMC type
31: Number of display language (comment)
32: CNC display language number 1
33: Comment set number 1
(BINARY or BCD)
(Presence: YES, Absence: NO)
(32i-A PMC(3rd, EXT))
(1-16)
(-1, 0-127)
(0-16)
