15. PMC CONTROL FUNCTION
B–64113EN–1/01
1046
[Classification] Output signal
[Function] This signal reports that the control unit has finished reading the entered
data.
[Operation] The output condition and procedure are described in the “basic
procedure.”
[Classification] Output signal
[Function] This signal reports that program number search, specified by external data
input, has been completed.
[Output condition] This signal is set to “1” when:
The program number search specified by external data input is completed.
The signal is set to “0” when:
· An automatic operation is started.
· A reset occurs.
[Classification] Output signal
[Function] Informs the PMC that a program number search has been canceled.
[Output condition] If a reset signal is input between the time the ESTB signal (read signal for
external data input) has been input and the time a search would be
executed, the external program number search function keeps the search
from being executed if the ESC (bit 3 of parameter No. 6300) is 1. The
controller sets, to 1, the ESCAN signal (search cancel signal for external
data input) rather than the ESEND signal (search completion signal for
external data input).
NOTE
This signal is valid only if the ESC parameter (bit 3 of
parameter No. 6300) is 1.
Read completion signal
for external data input
EREND <F060#0>
Search completion
signal for external data
input ESEND <F060#1>
Search cancel signal for
external data input
ESCAN <F060#2>
