Connection manual (Function)
B–64113EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
379
1460 Upper limit of feedrate for the F1–digit feed command (F1 to F4)
1461 Upper limit of feedrate for the F1-digit feed command (F5 to F9)
[Data type] Two–word
Increment system
Unit of data
Valid data range
Increment s
y
stem
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 – 15000 6 – 12000
Inch machine 0.1 inch/min 6 – 6000 6 – 4800
Rotation axis 1 deg/min 6 – 15000 6 – 12000
Set the upper limit of feedrate for the F1-digit feed command.
As the feedrate increases by turning the manual pulse generator, the
feedrate is clamped when it reaches the upper limit set. If an F1-digit feed
command F1 to F4 is executed, the upper limit is that set in parameter
1460. If an F1-digit command F5 to F9 is executed, the upper limit is that
set in parameter 1461.
Series 0i–C
OPERATOR’S MANUAL
(M series) (B–64124EN)
II.5.3 Cutting feed
Series 0i Mate–C
OPERATOR’S MANUAL
(M series) (B–64144EN)
II.5.3 Cutting feed
[Unit of data]
[Valid data range]
Reference item
Previous page
Next page
