0i/0i Mate - Model C Connection manual (Function) Page 945

Connection manual (Function)

Page of 1224

/ 1224

B–64113EN–1/01

13. INPUT/OUTPUT OF DATA

927

(1) I/O Link specification signal

IOLS

(6)

(14)Slave input/output data

selection signals EPRG,

EVAR, EPARM, EDGN

(2) External read/punch signal

EXRD/EXWT

(3) I/O Link confirmation signal

IOLACK

(4) Power Mate read/write in–

progress signal BGION

(5) Power Mate read/write alarm

signal BGIALM

(6) Power Mate background

busy signal BGEN

(11) Read/punch alarm signal

RPALM

(12)Background busy signal

BGEACT

(13)Slave external read/write

start signal ERDIO/EWTIO

(15)Slave read/write stop signal

ESTPIO

(7) Program No.

(8) Group number specification

signal SRLNIx

(9) Slave I/O Link selection

signal IOLNK

(16)Group number output signal

SRLNOx

(10)Read/punch in–progress

signal RPBSY

(9) (10)

(3)

(4)

(13)

(9)

(1)

(2)

(11)

(8)

(5)

(13)

(7)

(5)

(12)

(11)
