0i/0i Mate - Model C Connection manual (Function) Page 306

Connection manual (Function)
5. AUTOMATIC OPERATION
B–64113EN–1/01
288
1420 Rapid traverse rate for each axis
[Data type] Two–word axis
Increment system
Unit of data
Valid data range
Increment s
y
stem
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 30 – 240000 6 – 100000
Inch machine 0.1 inch/min 30 – 96000 6 – 48000
Rotation axis 1 deg/min 30 – 240000 30 – 100000
Set the rapid traverse rate when the rapid traverse override is 100% for
each axis.
1422 Maximum cutting feedrate for all axes
[Data type] Two–word
Increment system
Unit of data
Valid data range
Increment s
y
stem
Unit of data
IS-A, IS-B IS-C
Millimeter machine 1 mm/min 6 – 240000 6 – 100000
Inch machine 0.1 inch/min 6 – 96000 6 – 48000
Specify the maximum cutting feedrate.
A feedrate in the tangential direction is clamped in cutting feed so that it
does not exceed the feedrate specified in this parameter.
NOTE
To specify the maximum cutting feedrate for each axis, use
parameter No. 1430 instead. (M series)
Series 0i–C
OPERATOR’S MANUAL
(M series) (B–64124EN)
III.5.4 Dry run
Series 0i–C
OPERATOR’S MANUAL
(T series) (B–64114EN)
III.5.4 Dry run
Series 0i Mate–C
OPERATOR’S MANUAL
(M series) (B–64144EN)
III.5.4 Dry run
Series 0i Mate–C
OPERATOR’S MANUAL
(T series) (B–64134EN)
III.5.4 Dry run
[Unit of data]
[Valid data range]
[Unit of data]
[Valid data range]
Reference item
