0i/0i Mate - Model C Connection manual (Function) Page 224

Connection manual (Function)
B–64113EN–1/01
3. MANUAL OPERATION
206
12350 Manual handle feed magnification m (in each axis)
[Data type] Word axis
[Unit of data] 1
[Valid data range] 1 to 127
This parameter sets the magnification to be used for each axis when
manual handle feed movement amount select signal MP1 <G019#4> is
set to 0, and MP2 <G019#5> is set to 1.
If this parameter is set to 0 for a target axis for movement, the setting of
parameter No. 7113 applies.
12351 Manual handle feed magnification n (in each axis)
[Data type] Word axis
[Unit of data] 1
[Valid data range] 1 to 1000
This parameter sets the magnification to be used for each axis when
manual handle feed movement amount select signal MP1 <G019#4> is
set to 1, and MP2 <G019#5> is set to 1.
If this parameter is set to 0 for a target axis for movement, the setting of
parameter No. 7114 applies.
Movement amount select signal
Movement amount (manual handle
feed or manual handle interrupt)
MP2 MP1
Movement amount (manual handle
feed or manual handle interrupt)
0 0 Least input increment 1
0 1 Least input increment 10
1 0 Least input increment m (*1)
1 1 Least input increment n (*2)
*1 When 0 is set in parameter No. 12350 for setting a movement target
axis magnification, parameter No. 7113 is used.
*2 When 0 is set in parameter No. 12351 for setting a movement target
axis magnification, parameter No. 7114 is used.
WARNING
Rotating the handle quickly with a large magnification such
as x100 moves the tool too fast or the tool may not stop
immediately after the handle is no longer rotated or the
distance the tool moves may not match the graduations on
the manual pulse generator. The feedrate is clamped at the
rapid traverse rate.
