0i/0i Mate - Model C Connection manual (Function) Page 450

Connection manual (Function)
B–64113EN–1/01
7. FEEDRATE CONTROL/ACCELERATION
AND DECELERATION CONTROL
432
When the non–linear interpolation type is selected, movement is
performed at the feedrate set in parameter No. 1420 with
acceleration/deceleration set in parameter No. 1620. The corresponding
value can be set in parameter No. 1621 to select bell–shaped
acceleration/deceleration.
NOTE
Rapid traverse block overlap is disabled.
Axis control f : Can be specified. : Cannot be specified.
Name Function
Number of controlled axes 3 to 4
Number of simultaneously con-
trolled axes
Up to 4
Axis name The basic three axes are fixed to X, Y, and Z.
Other axes are any of U, V, W, A, B, and C.
Least input increment 0.001 mm, 0.001 deg, 0.0001 inch
One–tenth input increment 0.0001 mm, 0.0001 deg, 0.00001 inch
One–tenth input increment for each axis cannot be
used.
Simple synchronous control f However, switching between synchronous and
normal operation cannot be performed during
automatic operation (when the automatic op-
eration signal (OP) is set to 1) regardless of
whether the AI advanced preview control/AI
contour control mode is set. In this case,
switching causes a PS213 alarm.
Angular axis control
Inch/metric conversion
(G20, G21)
f (*1)
Interlock f
Interlock for each axis f Movement along all axes stops.
To stop movement only along the interlock axis
in non–linear interpolation type positioning, set
bit 5 (AIL) of parameter No. 7054 to 1 and bit 4
(XIK) of parameter No. 1002 to 0.
Machine lock f When the machine lock signal for each axis
(MLK1 to MLK8) is turned on or off, accelera-
tion/deceleration is not applied to the axis for
which machine lock is performed.
Mirror image f
Stored pitch error compensation f
Position switch f Set bit 3 (PSF) of parameter No. 6901 to 1.
When this parameter is set to 1, the signal out-
put timing changes.
Abnormal load detection f
Manual handle interruption f Manual handle interruption is disabled during
switching to the AI advanced preview control/AI
contour control mode.
External pulse synchronization
D Specifications
