B–64113EN–1/01
2. PREPARATIONS FOR OPERATION
175
The table below lists the status output signals. They indicate the state of
the CNC. See the sections listed in the table for details of each signal.
Signal name Symbol Reference section
Alarm signal AL 2.4
Battery alarm signal BAL 2.4
Reset signal RST 5.2
Rewinding signal RWD 5.2
Tapping signal TAP 11.6
Moving signal MV1 – MV4 1.2.5
Moving direction signals MVD1 – MVD4 1.2.5
In–position signals INP1 – INP4 7.2.5.1
Rapid traversing signal RPDO 2.7 (the section you are
reading)
Cutting feed signal CUT 2.7 (the section you are
reading)
Thread cutting signal THRD 6.4.1
Constant surface speed
signal
CSS 9.4
Inch input signal INCH 11.4
[Classification] Output signal
[Function] This signal indicates that a move command is being executed at rapid
traverse.
[Output condition] “1” indicates an axis starts moving after rapid traverse has been selected;
“0” indicates that an axis starts moving after a feedrate other than rapid
traverse has been selected. This holds true for both automatic and manual
operation modes.
2.7
STATUS OUTPUT
SIGNAL
General
Signal
Rapid traversing signal
RPDO <F002#1>
