0i/0i Mate - Model C Connection manual (Function) Page 48

Connection manual (Function)
B–64113EN–1/01
1. AXIS CONTROL
30
· Interval of the pitch error compensation positions (for each axis):
Parameter 3624
1 Set the following parameters:
⋅ Pitch error compensation position at the reference position (for
each axis): Parameter 3620
⋅ Pitch error compensation position having the smallest value (for
each axis): Parameter 3621
⋅ Pitch error compensation position having the largest value (for
each axis): Parameter 3622
⋅ Pitch error compensation magnification (for each axis):
Parameter 3623
⋅ Interval of the pitch error compensation positions (for each
axis): Parameter 3624
2 Press function key
SYSTEM
.
3 Press the continuous menu key
, then press chapter selection soft
key
[PITCH].
The following screen is displayed:
PIT–ERROR SETTING O0000 N00000
NO. DATA
0000 0
0001 0
0002 0
0003 0
0004 0
0005 0
0006 0
0007 0
0008 0
0009 0
NO. DATA
0010 0
0011 0
0012 0
0013 0
0014 0
0015 0
0016 0
0017 0
0018 0
0019 0
NO. DATA
0020 0
0021 0
0022 0
0023 0
0024 0
0025 0
0026 0
0027 0
0028 0
0029 0
(X)
> _
MEM **** *** *** 16:05:59
[ NO.SRH ][ ON:1 ][ OFF:0 ][ +INPUT ][ –INPUT ]
4 Move the cursor to the compensation position number to be set in
either of the following ways:
⋅ Enter the compensation position number and press the
[NO.SRH] soft key.
⋅ Move the cursor to the compensation position number using the
page keys,
PAGE
and
PAGE
, and cursor keys, , , ,
and
.
5 Enter a value with numeric keys and press the [INPUT] soft key.
Procedure for displaying
and setting the pitch
error compensation data
PITCH
Continuous menu key
Previous page
Next page
