0i/0i Mate - Model C Connection manual (Function) Page 112

Connection manual (Function)
B–64113EN–1/01
1. AXIS CONTROL
94
Parameter No. Meaning of parameters
0012#0
0012#7
1004#7
1005#4
1005#5
1005#7
1022
1220
1221
1222
1223
1224
1225
1226
1423
1424
1425
1427
1430
1815#1
1815#5
2008#2
Mirror image
Servo control off
Input unit 10 times
External deceleration in plus direction
External deceleration in minus direction
Servo control off
Parallel axis specification
External workpiece coordinate shift
Workpiece zero point offset by G54
Workpiece zero point offset by G55
Workpiece zero point offset by G56
Workpiece zero point offset by G57
Workpiece zero point offset by G58
Workpiece zero point offset by G59
Jog feedrate
Manual rapid traverse
FL rate in manual reference position return
External deceleration rate at rapid traverse
Maximum feedrate
Separate type pulse coder
Absolute pulse coder
Velocity feedback average function
Parameter No. Meaning of parameters
1020
1023
2022
2087
3115
Axis name
Servo axis number
Motor rotation direction
Preload value
Current position display
1310#0
1310#1
1320
1321
1322
1323
1815#1
1816#6 to #4
1821
2024
2084
2085
Soft OT2
Soft OT3
1st stroke limit of plus side
1st stroke limit of minus side
2nd stroke limit of plus side
2nd stroke limit of minus side
Separate type pulse coder
Detection multiplier (DMR)
Arbitrary reference counter capacity
Position detection feedback pulses (PPLS)
Numerator of flexible feed gear ratio
Denominator of flexible feed gear ratio
Parameters that should
be set only for the
master axis
Parameters that may be
set to different values for
the master and slave
axes
Previous page
Next page
