12. DISPLAY/SET/EDIT
B–64113EN–1/01
858
#7
3115
#6 #5 #4 #3
NDFx
#2 #1 #0
[Data type] Bit axis
NDFx To the actual speed display, axis movement data is:
0 : Added.
1 : Not added.
NOTE
Even if the parameter PCF (bit 1 of parameter No.3105) is
set to 0, so as to add PMC controlled axis movement data
to the actual speed display, the movement data for a PMC
controlled axis for which NDFx is set to 1 is not added to the
actual speed display.
The parameter set supporting screen is a parameter setting and tuning
screen intended to help:
D Readily start up the machine by collecting and displaying the
minimum required parameters for machine launching.
D Smoothly make adjustments by easily displaying the servo, spindle,
and machining parameter tuning screens.
The following two methods can be used to display the parameter set
supporting screen.
(1)Press the [SYSTEM] function key several times until the parameter set
supporting screen appears.
Parameter Diagnosis Parameter set supporting screen
Setting the CPR parameter (bit 2 of parameter No. 3195) to 1 disables
the function key from displaying the parameter set supporting screen.
If you want to use the conventional method for displaying the screen,
use this parameter so that you can follow the method given below.
12.1.21
Parameter Set
Supporting Screen
General
Operation
Previous page
Next page
