9. SPINDLE SPEED FUNCTION
593
[Classification] Output signal
[Function] This signal indicates that Cs axis coordinate setup has not normally been
completed.
[Output condition] The signal becomes ’1’ under the following condition:
– Cs axis coordinate setup is not normally completed.
The signal becomes ’0’ under the following conditions:
– The Cs contour control mode is exited.
– The corresponding Cs axis coordinate set request signal CSFI1
<G274#4> becomes ’0’.
[Classification] Output signal
[Function] This signal indicates that it is possible to perform Cs axis coordinate setup
processing.
[Output condition] The signal becomes ’1’ under the following condition:
S A reference position return is normally completed during Cs contour
control mode.
The signal becomes ’0’ under the following condition:
S A spindle alarm is detected or the spindle motor rotates faster than the
maximum allowable rotation speed (No. 4020).
#7
G274
#6 #5 #4
CSFI1
#3 #2 #1 #0
#7
F048
#6 #5 #4
CSPENA
#3 #2 #1 #0
#7
F274
#6 #5 #4
CSFO1
#3 #2 #1 #0
Cs axis coordinate setup
alarm signal
CSFO1 <F274#4>
Cs axis origin setup
status signal
CSPENA <F048#4>
Signal address
