0i/0i Mate - Model C Connection manual (Function) Page 61

Connection manual (Function)
B–64113EN–1/01
1. AXIS CONTROL
43
As pitch error data, always set incremental values as viewed in the
negative direction (direction toward the left in Fig. 1.3.3 (b)).
Table 1.3.3 (c) Negative–direction pitch error data
Compensation
point number
30 31 32 33 34 35 36 37
Compensation
amount to be set
–1 +1 –1 +2 –1 +2 –1 –2
Set negative–direction pitch error data for all the points for which
positive–direction pitch error data has been set.
As negative–direction pitch error data, always set incremental values as
viewed in the negative direction.
Table 1.3.3 (d)
Data
number
Setting Description
3605#0 1 Bidirectional pitch error compensation,
1: Enabled / 0: Disabled
3620 23 Number of the pitch error compensation point for the
reference position
3621 20 Number of the most distant pitch error compensation
point on the – side for travel in the positive direction
3622 27 Number of the most distant pitch error compensation
point on the + side for travel in the positive direction
3623 1 Pitch error compensation magnification
3624 10000 Pitch error compensation point interval
3625 – For a rotation axis, amount of travel per rotation in
pitch error compensation
3626 30 Number of the most distant pitch error compensation
point on the – side for travel in the negative direction
3627 –2 Pitch error compensation amount (absolute value) at
the reference position when the machine moves to
the reference position in the direction opposite to that
of the reference position return
This example assumes that the direction of a manual reference position
return is positive. For parameter No. 3627, therefore, set –2, which is the
pitch error compensation amount (absolute value) at the reference
position when the machine moves to the reference position in the negative
direction.
