B–64113EN–1/01
9. SPINDLE SPEED FUNCTION
581
NOTE
1 In the T series, when G code system A is used, neither U,
V, nor W can be used as an axis name. Only when G code
system B or C is used, U, V, and W can be used as axis
names.
2 The same axis name cannot be assigned to more than one
axis.
3 When the optional function of the second auxiliary function
is provided, however, the address (B for the T series or the
address specified by parameter No. 3460 for the M series)
for the second auxiliary function command cannot be used.
In the T series, when address A or C is used, set parameter
CCR (No. 3405#4) to 0.
4 If you use letter E as an axis name in format F10/11, be sure
to use address F in the major–axis direction lead command
for equal–lead threading (G32).
Any axis name can be used for Cs contour control axis except for above
limitation.
1022 Setting of each axis in the basic coordinate system
[Data type] Byte axis
Only one axis can be set for each of the three basic axes X, Y, and Z, but
two or more parallel axes can be set.
Set value Meaning
0 Neither the basic three axes nor a parallel axis
1 X axis of the basic three axes
2 Y axis of the basic three axes
3 Z axis of the basic three axes
5 Axis parallel to the X axis
6 Axis parallel to the Y axis
7 Axis parallel to the Z axis
Set 0 to the Cs contour control axis.
1023 Number of the servo axis for each axis
[Data type] Byte axis
Set the servo axis for each control axis.
Generally, the same number shall be assigned to the control axis and the
corresponding servo axis.
Set –1 as the number of servo axis to the Cs contour control axis.
