B–64113EN–1/01

9. SPINDLE SPEED FUNCTION

514

Although the S command contains the spindle speed, the object that is

actually controlled is the spindle motor. Therefore, the CNC must have

some provision to detect the gear stage between the speed and spindle

motor.

There are two types of gear selection methods:

M type

The CNC selects a gear stage according to the range of speed for each gear

stage previously specified in a parameter, as directed by the S command,

and informs the PMC of the selected gear stage (one of the three gear

stages ) using the gear select signal output (GR3O, GR2O, GR1O).

Also, the CNC outputs the spindle speed based on the selected gear stage

(output as the gear select signal).

T type

The gear stage (one of the four gear stages ) being currently used by the

machine is specified by the gear select signal inputs (GR1, GR2).

The machine determines which gear to use.

The CNC outputs the appropriate speed command for the selected gear

range.

The M series system can use either M or T type.

M type ← Without constant surface speed control option, and bit 4

(GTT) of parameter No. 3706 = 0

T type ← With constant surface speed control, or bit 4 (GTT) of

parameter No. 3706 = 1

The T series system can use only T type.

By specifying from S0 to S99999 in memory or MDI operation, the CNC

outputs a command corresponding to the spindle speed. There is a

two-speed (GR1O and GR2O) or three-speed range (GR1O, GR2O,

GR3O), set by parameter nos. 3741-3743, and the gear selection signal

is output simultaneously. When the gear selection signal is changed, the

SF signal is output at the same time (parameter SFA no. 3705#6).

The meaning of the gear signals is shown below:

Gear 2–stage Gear 3–state Remarks

GR1O Low Low

Low: Low Gear

GR2O High Middle

Low: Low Gear

Middle: Middle Gea

High: High Gear

GR3O High

High: High Gear

D Processing for gear

changing

D Selection of gear change

system

D Details of M type

(Output of GR1O, GR2O,

GR3O)
