B–64113EN–1/01

1. AXIS CONTROL

1874 Flexible feed gear numerator for built–in position detector

1875 Flexible feed gear denominator for built–in position detector

[Data type] Word axis

[Valid data range] 1 to 32,767

Specifies a flexible feed gear for a built–in position detector for each axis

when using tentative coordinate system setting, according to the

following expression:

Number of position feedback pulses per

motor revolution

NO.1874

NO.1875 1,000,000

NOTE

1 These parameters can be used also in a system that uses

the Inductosyn.

2 After setting any of these parameters, turn the power off

then on again so that the setting will take effect.

XIAx2011

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit axis

INI Specifies whether to enable tentative absolute coordinate system setting,

as follows:

0 : To disable.

1 : To enable.

NOTE

Using tentative absolute coordinate system setting requires

setting bit 1 (OPTx) of parameter No. 1815, bit 5 (APCx) of

parameter No. 1815, parameter No. 1874, and parameter

No. 1875.
