6. INTERPOLATION FUNCTION

B–64113EN–1/01

330

3708

#6 #5 #4 #3 #2 #1

SAT

SAR

[Data type] Bit

SAR: The spindle speed arrival signal is:

0 : Not checked

1 : Checked

SAT: Check of the spindle speed arrival signal at the start of executing the

thread cutting block

0 : The signal is checked only when SAR, #0 of parameter 3708, is set.

1 : The signal is always checked irrespective of whether SAR is set.

CAUTION

When thread cutting blocks are consecutive, the spindle

speed arrival signal is not checked for the second and

subsequent thread cutting blocks.

Time constant of exponetial acceleration/deceleration in the thread

cutting cycle for each axis

1626

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

Set the time constant used for exponential acceleration/deceleration in the

thread cutting cycle (G76, G78 (G92 in G code system A)) for each axis.

Checking the spindle

speed arrival signal

before starting threading

Setting the time constant

for the threading cycle
