B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 97 -

1460

Upper limit of feedrate for the one-digit F code feed command (F1 to F4)

1461

Upper limit of feedrate for the one-digit F code feed command (F5 to F9)

[Data type] 2-word

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

Set the upper limit of feedrate for the one-digit F code feed command.

As the feedrate increases by turning the manual pulse generator, the

feedrate is clamped when it reaches the upper limit set. If a one-digit F

feed command F1 to F4 is executed, the upper limit is that set in

parameter No. 1460. If a one-digit F code feed command F5 to F9 is

executed, the upper limit is that set in parameter No. 1461.
