Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 577

Parameter manual
B-63530EN/03 4.DESCRIPTION OF PARAMETERS
- 565 -
#7 #6 #5 #4 #3 #2 #1 #0
NF3 BPF COF
8242
[Data type] Bit
COF The amount of the B-axis offset is set:
0: Separately for each path.
1: Simultaneously for all paths.
BPF For feed per revolution with the B-axis control function, the
parameters for the unit of PMC feedrate data specification, bits 6
(FR1) and 7 (FR2) of parameter No. 8002 are:
0 : Valid.
1 : Invalid.
NF3 An axis number used for B-axis control on path 3 (in the case of
three-path control) is specified in:
0 : Single operation format (1 to n).
1 : Multi-path-operation format (31 to 3n).
(n: Number of axes of path 3)
