4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 304 -

4811

Allowable error count for the error pulses between two spindles in the serial

spindle synchronous control mode or simple synchronous control mode

[Data type] Word

[Unit of data] Pulse

[Valid data range] 0 to 32767

Set the allowable error count for the error pulses between two spindles

in the serial spindle synchronous control mode or simple synchronous

control mode.

NOTE

This parameter is used to output the inter-spindle

phase error detection signal SYCAL in the serial

spindle synchronous control mode. The SYCAL

<F044#4> signal becomes "1" when a phase error

exceeding the value set in this parameter is found.

When you are going to use this parameter to detect

error pulses during simple synchronous control,

pay attention to the mode of the spindle, and set

the parameter as required. (The parameter is

invalid in spindle mode. It is valid in Cs contour

control, rigid tapping, and spindle positioning mode;

the detection unit per pulse differs, however.)

Master spindle in spindle synchronous control

4812

Slave spindle in spindle synchronous control

4813

[Data type] Byte

[Valid data range] 0, 1 to number of spindles or m × 10+n (m: 1 to number of paths, n: 1

to number of spindles)

Set a master spindle/slave spindle in spindle synchronous control.

[Setting value] 1 to 4 : First to fourth serial spindle of the local path

11 to 14 : First to fourth serial spindle of path 1

21 to 24 : First to fourth serial spindle of path 2

31 to 34 : First to fourth serial spindle of path 3

NOTE

These parameters are valid only under spindle

synchronous control by CNC program. If spindle

synchronous control ON (G51.8) is specified by

programming when 0 is set, an alarm is issued.
