Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 243

Parameter manual
B-63530EN/03 4.DESCRIPTION OF PARAMETERS
- 231 -
#7 #6 #5 #4 #3 #2 #1 #0
3232 P9D P8D ND9 ND8
[Data type] Bit
ND8 When a program with a program number from 8000 to 8999 is being
executed as a subprogram or macro program, the display of the
program on the program screen is:
0 : Not prohibited.
1 : Prohibited.
ND9 When a program with a program number from 9000 to 9999 is being
executed as a subprogram or macro program, the display of the
program on the program screen is:
0 : Not prohibited.
1 : Prohibited.
P8D When a program with a program number from 80000000 to 89999999
is being executed as a subprogram or macro program, the display of
the program on the program screen is:
0 : Not prohibited.
1 : Prohibited.
P9D When a program with a program number from 90000000 to 99999999
is being executed as a subprogram or macro program, the display of
the program on the program screen is:
0 : Not prohibited.
1 : Prohibited.
