B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 235 -

3294 Start number of tool offset values whose input by MDI is disabled

3295

Number of tool offset values (from the start number) whose input by MDI is

disabled

[Data type] Word

When the modification of tool offset values by MDI key input is to be

disabled using bit 0 (WOF) of parameter No.3290 and bit 1 (GOF) of

parameter No.3290, parameter Nos. 3294 and 3295 are used to set the

range where such modification is disabled. In parameter No.3294, set

the offset number of the start of tool offset values whose modification

is disabled. In parameter No.3295, set the number of such values.

When 0 or a negative value is set in parameter No.3294 or parameter

No.3295, no modification of the tool offset values is allowed.

When the value set with parameter No.3294 is greater than the

maximum tool offset count, no modification is allowed.

[Example] The following setting disables the modification of both the tool

geometry compensation values and tool wear compensation values

corresponding to offset numbers 51 to 60:

Bit 1 (GOF) of parameter No.3290=1 (Disables tool offset value

modification.)

Bit 0 (WOF) of parameter No.3290=1 (Disables tool wear

compensation value modification.)

Parameter No.3294 = 51

Parameter No.3295 = 60

If bit 0 (WOF) of parameter No.3290 is set to 0, the modification of

the tool offset values alone is disabled. The tool wear compensation

values may be modified.

#7 #6 #5 #4 #3 #2 #1 #0

3301 HDC HCG HCA HCC

[Data type] Bit

HCC In the VGA-compatible mode display,

0 : A 256-color bit map data of the screen hard copy is created.

1 : A 16-color bit map data of the screen hard copy is created.

HCA An alarm message related to hard copy is:

0 : Not displayed.

1 : Displayed.

HCG In a monochrome bit map data of the screen hard copy,

0 : Black and white are not inverted. (same as the screen image)

1 : Black and white are inverted.

HDC A screen hard copy is:

0 : Not provided.

1 : Provided.

NOTE

For the Series 160i/180i/160is/180is, the screen

hard copy is unavailable.
