B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 61 -

WZP In the three-dimensional coordinate conversion mode, a modification

to the workpiece coordinate system from the MDI is:

0 : Not prohibited.

1 : Prohibited.

3DW When any of the following:

• Workpiece coordinate system selection (G54 to G59, G54.1P)

• Coordinate system setting (G50, G92)

• Local coordinate system (G52)

is specified in the three-dimensional coordinate conversion mode:

0 : An alarm is issued (P/S 049 alarm).

1 : No alarm is issued.

MMD In manual operation on an axis for which mirror image is enabled, the

move direction on the axis is:

0 : Not the same as the direction in automatic operation.

1 : Same as the direction in automatic operation.

NOTE

The move direction on an axis in manual operation

in the three-dimensional coordinate conversion

mode is the same as the direction in automatic

operation at all times, regardless of the setting of

this parameter.

#7 #6 #5 #4 #3 #2 #1 #0

R2O R1O

1203

[Data type] Bit

R1O The signal output of the first reference position is:

0 : Invalid.

1 : Valid.

The reference position signal output function is needed. See the

description of parameter No. 1245.

R2O The signal output of the second reference position is:

0 : Invalid.

1 : Valid.

The reference position signal output function is needed. See the

description of parameter No. 1246.
