SEB When a high-speed skip signal goes on while the skip function is used,

acceleration/deceleration and servo delay are:

0 : Ignored.

1 : Considered and compensated (type B).

NOTE

There are two types of compensation: Types A and B.

With the skip function, the current position is stored in

the CNC according to the skip signal. However, the

current position stored in the CNC contains servo

delay. The machine position is therefore deviated by

the servo delay. The deviation can be obtained from

the position deviation of the servo and the error

generated due to feedrate acceleration/deceleration

performed by the CNC. If the deviation can be

compensated, it is not necessary to include the servo

delay in measurement errors. The deviation can be

compensated with the following two types by the

parameter as follows:

(1) Type A: The deviation is the value calculated

from the cutting time constant and servo

time constant (loop gain).

(2) Type B: The deviation is the error due to

acceleration/deceleration and the

position deviation when the skip signal

goes on.

TSE When the torque limit skip function (G31 P99/98) is used, the skip

position held in a system variable is:

0 : Position that is offset considering the delay (positional deviation)

incurred by the servo system.

1 : Position that does not reflect the delay incurred by the servo

system.

NOTE

The torque limit skip function stores the current

position in the CNC when the torque limit arrival

signal is turned on. However, the current position in

the CNC includes a servo system delay, so that the

position is shifted from the machine position by an

amount corresponding to the servo system delay. The

value of this shift can be determined from the servo

system positional deviation. When TSE is set to 0, a

skip position is determined by subtracting the

positional deviation from the current position. When

TSE is set to 1, the current position (including the

servo system delay) is used as the skip position,

without considering any shift or position deviation.
