4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 264 -

SS2 In serial spindle control, the second spindle is:

0 : Not used.

1 : Used.

NOTE

This parameter is valid, when the spindle serial

output option is provided and bit 1 (ISI) of

parameter No.3701 is 0.

1 Confirmation of connection of the second serial

spindle amplifier, and communication with it

2 Control of the second spindle during

non-synchronous control (SIND2)

When this parameter is set, it is also necessary to

set the serial spindle parameter for the second

spindle.

SS3 In serial spindle control, the third spindle is:

0 : Not used.

1 : Used.

NOTE

This parameter is valid, the spindle serial output

option and the three-spindle serial output option

are provided.

Parameter setting

Bit 1 (SS4)

of No.3704

Bit 5 (SS3)

of No.3704

Bit 4 (SS2)

of No.3704

Serial spindles to be

used

0 0 0 First spindle only

0 0 1 First and second spindles

0 1 0 First and third spindles

0 1 1 First to third spindles

1 1 0

First, third, and fourth

spindles

1 1 1 First to fourth spindles

NOTE

1 To connect a serial spindle as the third or fourth

spindle, the function of three/four-spindle serial

output is required.

2 The fourth serial spindle can be used just in Series

16i/160i/160is.
