Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 277

Parameter manual

Page of 782

/ 782

B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 265 -

#7 #6 #5 #4 #3 #2 #1 #0

ECS ESS EAS ESI OR2 OR1 EMS OR3

3702

ECS ESS EAS OR2 OR1 EMS OR3

NOTE

When at least one of these parameters is set, the

power must be turned off before operation is

continued.

[Data type] Bit

OR3 The spindle orientation function based on an externally set stop

position is:

0 : Not used by the third spindle motor.

1 : Used by the third spindle motor.

NOTE

When the spindle orientation function based on an

externally set stop position is used, the position

coder-based spindle orientation stop position set

parameters (No.4031 and No.4204) are ineffective.

EMS Multi-spindle control function

0 : Used

1 : Not used

NOTE

Set this parameter for a path that does not require

multi-spindle control in 2-path or 3-path control.

OR1 Whether the stop-position external-setting type orientation function is

used by the first spindle motor

0 : Not used

1 : Used

OR2 Whether the stop-position external-setting type orientation function is

used by the second spindle motor

0 : Not used

1 : Used

ESI The spindle positioning function is

0 : Used

1 : Not used

NOTE

When the spindle positioning option is specified in

2-path or 3-path control, set this parameter for a

path that does not require the spindle positioning

function.

EAS For path 1, path 2, or path 3, the S analog output function is:

0 : Used.

1 : Not used.
