B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 173 -

1931

Connector number for the first separate detector interface unit (dedicated to

the FSSB setting screen)

1932

Connector number for the second separate detector interface unit (dedicated

to the FSSB setting screen)

NOTE

When these parameters are set, the power must be

turned off before operation is continued.

[Data type] Byte axis

[Valid data range] 0 to number of connectors provided on each separate detector

interface unit

When a separate detector interface unit is used, these parameters set a

separate detector interface unit connector number for each axis.

NOTE

These parameters are set using the FSSB setting

screen. So, these parameters should not normally

have to be specified directly. These parameters

need not be set in FSSB manual setting 2 mode.

1933 Cs contour control axis (dedicated to the FSSB setting screen)

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] Byte axis

[Valid data range] 0, 1

When Cs contour control is to be applied for an axis, this parameter

must be set to 1 for that axis.

NOTE

This parameter is set using the FSSB setting

screen. So, this parameter should not normally

have to be specified directly. This parameter need

not be set in FSSB manual setting 2 mode.
