4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 214 -

3141 Path name (1st character)

3142 Path name (2nd character)

3143 Path name (3rd character)

3144 Path name (4th character)

3145 Path name (5th character)

3146 Path name (6th character)

3147 Path name (7th character)

[Data type] Byte

Specify a path name with codes (two-path control).

Any character string consisting of alphanumeric characters, katakana

characters, and special characters with a maximum length of seven

characters can be displayed as a series name.

NOTE

1 These parameters are dedicated to the two-path

control.

Specify these parameters for each series.

2 For characters and codes, see the correspondence

table in Appendix A.

3 When codes are 0, HEAD1 and HEAD2 for T

series and PATH1 or PATH2 for M series are

displayed.

[Example] When the names of path 1 and 2 are specified as TURRET1 and

TURRET2, respectively.

(1) Setting for path 1 (2) Setting for path 2

Parameter No. 3141 = 84 (T) Parameter No. 3141 = 84 (T)

Parameter No. 3142 = 85 (U) Parameter No. 3142 = 85 (U)

Parameter No. 3143 = 82 (R) Parameter No. 3143 = 82 (R)

Parameter No. 3144 = 82 (R) Parameter No. 3144 = 82 (R)

Parameter No. 3145 = 69 (E) Parameter No. 3145 = 69 (E)

Parameter No. 3146 = 84 (T) Parameter No. 3146 = 84 (T)

Parameter No. 3147 = 49 (1) Parameter No. 3147 = 50 (2)
