4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 172 -

1920 Controlled axis number for slave 1 (dedicated to the FSSB setting screen)

1921 Controlled axis number for slave 2 (dedicated to the FSSB setting screen)

1922 Controlled axis number for slave 3 (dedicated to the FSSB setting screen)

1923 Controlled axis number for slave 4 (dedicated to the FSSB setting screen)

1924 Controlled axis number for slave 5 (dedicated to the FSSB setting screen)

1925 Controlled axis number for slave 6 (dedicated to the FSSB setting screen)

1926 Controlled axis number for slave 7 (dedicated to the FSSB setting screen)

1927 Controlled axis number for slave 8 (dedicated to the FSSB setting screen)

1928 Controlled axis number for slave 9 (dedicated to the FSSB setting screen)

1929 Controlled axis number for slave 10 (dedicated to the FSSB setting screen)

NOTE

When these parameters are set, the power must be

turned off before operation is continued.

[Data type] Byte

[Valid data range] 0 to 8

These parameters are used to set the controlled axis numbers for

slaves 1 to 10.

NOTE

These parameters are set using the FSSB setting

screen. So, these parameters should not normally

have to be specified directly. These parameters

need not be set in FSSB manual setting 2 mode.
