4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 162 -

#7 #6 #5 #4 #3 #2 #1 #0

1902 DCE STP ASE FMD

NOTE

When at least one of these parameters is set, the

power must be turned off before operation is

continued.

WARNING

Be sure to set bits 5 and 7 of parameter No. 1902

to 0. If any of these bits is set to 1, the safety

function may not operate normally.

[Data type] Bit

FMD The FSSB setting mode is:

0 : Automatic setting mode.

(When information including an axis-amplifier relationship is set

on the FSSB setting screen, parameter Nos. 1023, 1905, 1910

through 1919, 1936, and 1937 are set automatically.)

1 : Manual setting 2 mode.

(Set parameter Nos. 1023, 1905, 1910 through 1919, 1936, and

1937 manually.)

NOTE

When using the dual check safety function, set the

FMD parameter to 1 to set the manual setting 2

mode.

ASE When automatic setting mode is selected for FSSB setting (when the

FMD parameter (bit 0 of parameter No.1902) is set to 0), automatic

setting is:

0 : Not completed.

1 : Completed.

(This bit is automatically set to 1 upon the completion of

automatic setting.)
