B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 219 -

TRA If a point on the touch panel is kept pressed for a time specified in

parameter No. 3197 or longer,

0 : P/S alarm (No. 5303) is not raised.

1 : P/S alarm (No. 5303) is raised.

NOTE

1 If an C executer application or the like has a touch

panel repeat (continue pressing) function, set this

parameter to 0.

2 In open CNC, the parameter is valid just for the

CNC screen display function.

RDM Machine remote diagnosis message notification function is:

0 : Valid.

1 : Invalid.

PLD When a 9.5/10.4-inch display unit is used, current position display on

the left side of the display screen in a 1-path system, and the servo

axis load meter and spindle load meter display function on the

program check screen in a 2-path or 3-path system are:

0 : Disabled.

1 : Enabled.

#7 #6 #5 #4 #3 #2 #1 #0

RPR RPD

3194

DPD DPR

[Data type] Bit

RPD When the diameter/radius dynamic switching function is enabled and

the radius value command mode is set, an absolute coordinate, relative

coordinate, and distance to go on a diameter axis are:

0 : Displayed as radius values. (Half of diameter values)

1 : Displayed as diameter values.

RPR When the diameter/radius dynamic switching function is enabled and

the radius value command mode is set, a machine coordinate on a

diameter axis is:

0 : Displayed as a diameter value.

1 : Displayed as a radius value. (Half of a diameter value)

DPR When the diameter/radius dynamic switching function is enabled and

the diameter value command mode is set, an absolute coordinate,

relative coordinate, and distance to go on a radius axis are:

0 : Displayed as diameter values. (Two times greater than radius

values)

1 : Displayed as radius values.

DPD When the diameter/radius dynamic switching function is enabled and

the diameter value command mode is set, a machine coordinate on a

radius axis is:

0 : Displayed as a radius value.

1 : Displayed as a diameter value. (Two times greater than a radius

value)
