B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 277 -

THR The type of threading is:

0 : Type A

1 : Type B. (Be sure to set this parameter to 1 when PMC axis

control is used during execution of threading.)

#7 #6 #5 #4 #3 #2 #1 #0

CSL

3710

CSL SGR

[Data type] Bit

SGR When method B is selected (by setting bit 3 (SGT) of parameter No.

3705 to 1) for spindle gear switching in a rigid tapping cycle (G84,

G74), gear switching method B is used:

0 : For both of tapping and rigid tapping.

1 : For rigid tapping only.

CSL An axis for which fine acceleration/deceleration is disabled in the Cs

contour control mode is:

0 : Selected using the signal (CDFn<G0127>) from the PMC (n = 1

to 8).

1 : Axis (parameter No. 39n0) subject to interpolation with the Cs

contour control axis (n = 0 to 4).

Bit 0 (CAL) of

parameter No. 3712

Bit 6 (CSL) of

parameter No. 3710

Operation

0 0

When the spindle of the local path is placed in the Cs contour

control mode, fine acceleration/deceleration for an axis

selected with CDFn<G00127> of the local path is disabled (n

= 1 to 8).

0 1

When the spindle of the local path is placed in the Cs contour

control mode, fine acceleration/deceleration for an axis

(parameter No. 39n0) subject to interpolation with the Cs

contour control axis of the local path is disabled (n = 0 to 4).

1 0

When the spindle of a path in a multi-path system is placed in

the Cs contour control mode, fine acceleration/deceleration for

an axis selected with CDFn<G00127> of the local path is

disabled (n = 1 to 8).

1 1

When the spindle of a path in a multi-path system is placed in

the Cs contour control mode, fine acceleration/deceleration for

an axis (parameter No. 39n0) subject to interpolation with the

Cs contour control axes of all paths is disabled (n = 0 to 4).
