4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 626 -

12042 Program number for embedded macro (eighth set)

12045 Program number for embedded macro (ninth set)

12048 Program number for embedded macro (tenth set)

[Data type] 2-word

[Valid data range] 1 to 99999999

12022 G code macro count for embedded macro (first set)

12025 G code macro count for embedded macro (second set)

12028 G code macro count for embedded macro (third set)

12031 G code macro count for embedded macro (fourth set)

12034 G code macro count for embedded macro (fifth set)

12037 G code macro count for embedded macro (sixth set)

12040 G code macro count for embedded macro (seventh set)

12043 G code macro count for embedded macro (eighth set)

12046 G code macro count for embedded macro (ninth set)

12049 G code macro count for embedded macro (tenth set)

[Data type] Byte

[Valid data range] 1 to 255

These parameters specify G code macros for embedded macros. A G

code, corresponding macro program number, and corresponding G

code count are specified. Up to ten sets of these items can be specified.

If identical G code numbers are found, the one in a younger set takes

priority. If any of the G code number, macro program number, and

count is 0, the set is invalid.

[Example] Suppose that embedded macro program numbers are 7000 to 8999.

First set Second set Third set

G code No.12020=100 No.12023=150 No.12026=900

O number No.12021=8000 No.12024=7500 No.12027=8300

Count No.12022=10 No.12025=100 No.12028=30

If the parameters are specified as listed above,

The G codes from G100 to G109 correspond to O8000 to O8009.

The G codes from G150 to G249 correspond to O7500 to O7599.

The G codes from G900 to G929 correspond to O8300 to O8329.

NOTE

1 These parameters are rewritten by the embedded

macro data in FROM at power-up or at a reload

operation.

2 If the key of parameter No. 12013 is locked, the

embedded macro data in FROM is used.
